Jasic Air Compressor (EVO EP-80) Plasma Cutting Inverter

Jasic AP-140 Air Compressor (for EVO EP-80 Plasma Cutting Inverter)

The Jasic AP-140 Air Compressor is a dedicated companion for the EVO CUT 80 plasma inverter, designed to provide the consistent airflow needed for precision plasma cutting. Built with rugged construction, reliable performance, and compact integration in mind, the AP-140 ensures your EP-80 operates at maximum efficiency in workshop or site conditions.

Package Includes

• Jasic AP-140 Air Compressor Unit
  Integrated fittings for EVO EP-80 compatibility
  Operating manual

This is ideal for:

• Supplying stable compressed air to the EVO EP-80 Plasma Inverter
  Heavy-duty fabrication and cutting environments
  Workshop and on-site plasma cutting where consistent airflow is essential

Features

• Specifically designed for use with the Jasic EVO EP-80 Plasma Inverter
  Compact design with easy integration into EP-80 setup
  Reliable 0.4 MPa max pressure output
  145 l/min airflow for consistent cutting performance
  Rugged build quality with IP23S protection class
  Quiet and efficient with 2800 rpm motor speed
  Heavy-duty performance with insulation class H

Technical Specifications

Rated Input: AC 400 V, 50/60 Hz
Rated Input Current: 2.7 A
Power Capacity: 1.4 kVA
Max Pressure: 0.4 MPa
Rotation Speed: 2800 rpm
Air Flow: 145 l/min
Protection Class: IP23S
Insulation Class: H
Dimensions (AP-140 Unit): 547 × 230 × 318 mm
Dimensions (with EP-80): 626 × 230 × 734 mm
Weight (AP-140 Unit): 20 kg
Weight (with EP-80): 42 kg

Why Buy the Jasic AP-140 Air Compressor?

When paired with the EVO EP-80, the AP-140 provides the airflow stability required for smooth, precise plasma cutting. Its compact design, reliable motor performance, and easy integration make it an essential addition for professionals running the CUT 80. Built for durability and backed by Jasic’s renowned engineering standards, the AP-140 ensures you always get the best out of your plasma cutting system.
