Kemppi Master T 245 AC/DC GM Water-Cooled TIG/MMA Welder  (110/230v)
Kemppi Master T 245 AC/DC GM Water-Cooled TIG/MMA Welder  (110/230v) Kemppi Master T 245 AC/DC GM Water-Cooled TIG/MMA Welder  (110/230v) Kemppi Master T 245 AC/DC GM Water-Cooled TIG/MMA Welder  (110/230v) Master T – Master your craft with the compact-sized TIG welding machines

Kemppi Master T 245 AC/DC GM Water-Cooled TIG/MMA Welder (110/230v)

SKU: KEM/MST245ACDCGMWC | MPN: MST245ACDCGM

£5,665.20 £4,721.00
- +

#

Found it cheaper? Request a Price Match

0% interest for 4 months on orders over £99*
Choose PayPal Credit at the checkout. Find out more.

Overview

Kemppi Master T 245 AC/DC GM Water-Cooled TIG/MMA Welder – 110V / 230V

At Premier Welding we aim to offer amazing value for top quality products. The Kemppi Master T 245 AC/DC GM Water-Cooled is a professional AC/DC TIG and MMA welding system designed for welders who require maximum control, thermal stability, and productivity in demanding applications. Supporting single-phase 110V and 230V operation, as well as generator use, this advanced TIG welder delivers up to 240 amps, paired with a dedicated water-cooling unit for extended duty cycles and consistent torch performance.

The Master T range sets the benchmark for weld quality, usability, and energy efficiency in professional TIG welding. Smooth arc ignition, reduced noise levels in DC TIG welding, and excellent arc stability ensure consistent, high-quality results from start to finish. Weld Assist technology guides the welder to faster, more accurate setup, even at low current levels.

This water-cooled configuration is ideal for longer weld runs, higher current TIG work, and applications where heat management and operator comfort are critical. Designed and manufactured in Finland, the Master T system combines robust construction with advanced digital control for professional use in workshops or on site.

Package Includes

  • Kemppi Master T 245 ACDC GM AC/DC TIG/MMA power source
    7" TFT control panel (AC/DC compatible)
    Kemppi 4 Wheel Transport Unit w/ Cylinder Carrie
    Kemppi Flexlite TX 225G TIG torch – 4 m or 8m
    Earth return cable (35 mm² × 5 m)

This is ideal for:

  • Professional AC TIG welding of aluminium
    DC TIG welding of mild steel and stainless steel
    Higher-duty TIG welding requiring water-cooled torch performance
    MMA (stick) welding
    Fabrication workshops and industrial environments
    Site welding with generator power

What Does it Weld?

  • Aluminium (AC TIG)
    Mild steel
    Stainless steel
    Other steels suitable for DC TIG and MMA welding

Features

  • Power Source

    AC/DC TIG and MMA welding capability
    Multi-voltage 110V / 230V single-phase operation
    Generator compatible
    Maximum output 240 A
    Smooth arc ignition with reduced DC TIG noise levels
    Weld Assist for guided setup
    Double Pulse, MicroTack, and AutoCool functions
    MAX WeldClean electrolytic weld cleaning process
    DeMagnetization mode for improved arc stability
    Large 7-inch TFT colour display
    Remote control compatibility (hand, foot, and on-torch options)
    Robust, impact-resistant casing
    Designed and manufactured in Finland

  • MasterTig Cooler M

    Multi-voltage cooling unit
    Cooling power up to 1 kW
    3-litre coolant tank
    Maximum coolant pressure 4 bar
    Low idle power consumption (5 W)
    IP23S protection class
    Designed for continuous professional TIG welding

Technical Data

  • Kemppi Master T 245 AC/DC GM

    Input Voltage:
    110–120 V ±10 %
    220–240 V ±10 %

    Phases:
    1-phase, 50/60 Hz

    Rated Maximum Input Power:
    6 kVA

    Mains Fuse:
    16 A

    Idle Power:
    20 W

    Processes:
    AC TIG
    DC TIG

  • MMA

    TIG Output (230V):
    240 A @ 30% duty cycle
    200 A @ 60% duty cycle
    170 A @ 100% duty cycle

    TIG Output (110V):
    130 A @ 40% duty cycle
    120 A @ 60% duty cycle
    90 A @ 100% duty cycle

    MMA Output (230V):
    180 A @ 37% duty cycle
    150 A @ 60% duty cycle
    120 A @ 100% duty cycle

    MMA Output (110V):
    85 A @ 40% duty cycle
    75 A @ 60% duty cycle
    55 A @ 100% duty cycle

    Power Factor:
    0.99

    Efficiency:
    84 %

    EMC Class:
    A

    Welding Connection Type:
    R1/4

    Recommended Generator Size:
    8 kVA

    Protection Class:
    IP23

    Dimensions (L × W × H):
    544 × 205 × 443 mm

    Weight (without accessories):
    19.1 kg

    Standards:
    IEC 60974-1
    IEC 60974-3
    IEC 60974-10
    IEC 61000-3-12
    GB 15579.1

    Water Cooling Unit - Kemppi MasterTig Cooler M

    Supply Voltage:
    220–460 V ±10 %

    Cooling Power:
    0.9 kW @ 1 l/min
    1.0 kW @ 1.6 l/min

    Tank Volume:
    3 litres

    Maximum Coolant Pressure:
    4 bar

    Idle Power Consumption:
    5 W

    Operating Temperature:
    −20 °C to +40 °C

    Protection Class:
    IP23S

    Dimensions (L × W × H):
    615 × 206 × 268 mm

    Weight (without accessories):
    12.5 kg


    Combined System Weight
    Power Source:
    19.1 kg

    Cooling Unit:
    12.5 kg

    Total System Weight (without accessories):
    31.6 kg

Why Buy the Kemppi Master T 245 AC/DC GM Water-Cooled?

The Kemppi Master T 245 AC/DC GM Water-Cooled is engineered for professional welders who demand premium weld quality, advanced control, and reliable performance during extended TIG welding tasks. The addition of the MasterTig Cooler M allows longer weld times, improved torch comfort, and consistent results at higher currents. Backed by a 3-year global warranty, it is a future-ready TIG welding solution for demanding industrial applications.

Specifications

General

SKU
KEM/MST245ACDCGMWC
Weight (kg)
31.6
Manufacturer
Kemppi
Warranty
2 Years (extendable to 3 years)
GTIN / Barcode
6419240004916
MPN
MST245ACDCGM
