Heavy-Duty Pipe Cutting Saw
Exact PipeCut 360 Pro Series is intended for heavy-duty pipe cutting. Suitable for all pipe materials. Portable and easily transportable.
The set-up is fast and simple. The clean and user-friendly design makes it fast to mount on pipe sizes 75 mm – 360 mm (3”- 14”) and up with a maximum wall thickness of 20 mm (0.8”) steel, 50 mm (2”) plastics.
Exact PipeCut 360 Pro Series is the first and most popular pipe saw of the Pro Series product family. The machine is intended for professionals that appreciate easiness, fast cutting and accurate, straight cutting results. The machine creates only minimum amount of sparks and all in all is an extremely safe tool to use thanks to the user-friendly design.
Click HERE For Manual
THE MOST ADVANCED PIPE CUTTING SYSTEM EVER MADE!
Much stronger 2500W 230V / 2200W 110V motor.
Electronics protecting the motor from overload and “traffic lights” guiding the operator.
Laser indicator for precise cutting.
Improved adjustment mechanism for straight cutting.
Professional quality – Made in EU.
Cuts steel pipes with wall thickness up to 20 / 12 mm.
Package Includes
- Exact PipeCut 360 Pro Series pipe saw
- Pipe Supports 1 x Double, 2 x Small
- Operating instructions
- Hex socket key 5 mm and 2 mm fitted to the machine
- TCT 165 blade fitted to the machine
Technical Info
Pipe Material: Acid-resistant steel, Cast iron, Copper, Multi-layered materials, Plastic, Stainless steel, Steel
Pipe OD: 75mm – 360mm (3”- 14”)
Max Wall Thickness: 12mm (0.5") steel / 110V, 20mm (0.8”) steel / 230V, 45mm (2”) plastic
Voltage / Power: 230V / 2500W
Voltage / Current: 110V, 120V / 15A
No-Load speed: I=1900 r/min, II=2885 r/min
Blade diameter: 165mm (6.5”)
Mounting bore: 62mm (2.44”)
Weight: 17.5kg (38.6 lbs)
Electronical unit: Blade speed preselection, automatic fuse, soft start, torque control
Speed preselection: I = Stainless steel and acid-resistant steel, II = all other materials
Loading capacity of supports: 465 kg , 1025 lb (4 supports)
Technical Specification
Technical Specification
MPN | 7010413-110 |
SKU | 7010413-110 |
