Jasic Pro Tig 200P Digital Mini AC/DC TIG Welder | 240V
Information
Information
The Jasic Range comes with an incredible 5 Year Warranty
THIS PACKAGE INCLUDES
Pro Tig 200P Mini Digital AC/DC TIG Welder
Tig Torch & Adaptor
Gas Regulator
Work return lead & Clamp
Click here For brochure
Description
The JASIC TIG 200 Pulse AC/DC TIG Welder is a technologically advanced single-phase inverter power source. Its mainly suitable for medium to large production work. The innovative analog Panel is user-friendly and allows the user full control of the welding parameters.
The 200 AC/DC is an ideal choice for professionally qualified TIG welders that require precise and reliable peformance.
.
FEATURES
TIG Pulse AC/DC with Digital control
Digital display
Program memory storage
Easy to use, intuitive control panel
Pre-post flow time, up/down slope
Pulse adjustment
Pulse frequency, pulse duty, arc force, clean width
Remote control interface
AC function for aluminium and aluminium alloys
DC TIG function for carbon steel, stainless, copper and non-ferrous metals
Smooth arc and stable welding performance
Technical Data
Input Voltage (Single Phase) AC 230V - 50/60 Hz
Rated Input Current (A) 40
Current Range (A) MMA DC 10 - 160 MMA AC 20 - 160
TIG DC 10 - 200 TIG AC 20 - 200
Duty Cycle @ 40°C MMA 160A @ 40% TIG 200A @ 35%
No-Load Voltage (V) 60
Power Factor 0.93
Protection/Insulation Class IP21S/B
Dimensions (mm) 570 x 350 x 420
Weight (Kg) 9
Technical Specification
Technical Specification
MPN | JT-200DS |
SKU | JT-200DS |
